At CV+, we do things a little differently. Our focus is on delivering time-saving UCS packages designed to enhance your cabinet design process. With our unique catalogue, you’ll gain access to innovative tools that streamline your workflow and optimise precision in machining parts. Let us help you increase productivity and speed up your assembly process, ensuring you get the most out of your Cabinet Vision software. Embrace a new level of efficiency with CV+ and transform your design capabilities today.

New Products

Applied Bottom Panels
Applied Bottom Panels
$299.00

The CV+ Applied Bottom Panels UCS is you one stop shop for everything applied bottom panels. All controlled from the attributes bar. Simple, Easy. Fast!

  • Object Intelligence to Suit Cabinet

  • Adjust - Length, Position or Delete

  • LED Strip Lighting

  • Multiple Downlights

  • Window Reveals

  • Recessed or Drop Down Finger Grip

  • Need help installing? Limited support included with all packages

Under Mount Rangehoods
Under Mount Rangehoods
$149.00

The CV+ Rangehood UM UCS Makes Under Mount Rangehood Cabinets A Breeze With Full Control Via The Attribute Bar

  • Designed To Work With Or Without CV+ Applied Bot Panels UCS

  • Size Cutouts In The Cabinet Bottom & Applied Bottom. Adjust Cutouts Left / Right & In / Out From Wall

  • Setting The Height Automatically Positions A Fixed Shelf w/ Vent Cutout, Partitions & Rangehood / Vent Covers .

  • Option To Add Up To 2 Fixed Or Adjustable Shelves Either Side Of The Vent Duct. Vent Duct Centers Over Rangehood But Can Also Be Adjusted Left Or Right

  • Choose Between Top Or Rear Venting w/ Position Control.

  • User Defined Settings For Cover Setbacks, Route Tool, Vent Hole Diameter And Partition Morticing.

  • This UCS Only Works With The “CV+ Rangehood UM” Cabinet Provided In The CV+ Catalogue. Make A Copy But Do Not Rename Or Delete Internal Parts To Keep Functions.

  • Need help installing? Limited support included with all packages

Wall Scribes
Wall Scribes
$99.00

The CV+ Wall Scribes UCS allows users to quickly add wall scribes to base, wall and tall cabinets. Left, right or both. Then with easy to use attribute controls you can adjust the size and type of scribe. Inset, Flush or Mitered L-Shape.

  • Scribe material follows the material for fillers in your material schedule.

  • Flush Scribes - Set a minimum size for ABS edged parts. Part name indicates the finished size to be ripped to after banding. Scribe backing is also machined out of carcase material for fitment.

  • Mitered L-Shape scribes - Machined as a single piece ready to be mitered on the panel saw.

  • Inset Scribes - Machined to the width set in the attributes bar

  • Need help installing? Limited support included with all packages

Reverse Bevel Edge Marker
Reverse Bevel Edge Marker
$149.00

The CV+ Reverse Bevel Edge Marker UCS Marks The Edge Where Secondary Machining Is Needed To Create The R/Bevel Edge Finger Grip.

  • Control Edge Marking In Multiple Locations. Room Level Must Be Turned On If Any Doors Or Drawers Are To Have A Reverse Bevel Edge.

    • Room Level - Option to Apply Marker to Base, Tall Or Upper Cabinets Individually. I.e. Base Cabinets Only Or Any Combination

    • Cabinet Level - Set To On By Room Level Attribute. Turn Off If Specific Cabinet Doesn’t Require R/Bevel Edge Marker

    • Door & Drawer Front Level. Set To On By Cabinet Level Attribute. Turn Off If Specific Door Or Drawer Doesn’t Require R/Bevel Edge Marker

  • Marker Hole Positioning Is Automatic Depending On Cabinet Class (Door/Drawer Level Modification To Shift Marker To Different Edge)

    • Base - Top Edge Of Doors And Drawer.

    • Tall - Opposite Side To Hinges.

    • Upper - Bottom Edge Of Doors

  • Doors & Drawers With R/Bevel Marker Hole Enabled Automatically Have Pulls Removed. No Accidental Machining.

  • Marker Hole Tool, Diameter & Depth Can Be Set By User In UCS Public Variables.

  • This UCS Only Works Correctly With Doors And Drawers With Standard 4 Edges (Top, Bottom, Left & Right)

  • Need help installing? Limited support included with all packages

Dorset Ultra Slim Drawer System
Dorset Ultra Slim Drawer System
$349.00

This package adds Dorset Ultra Slim drawer system to Cabinet Vision. These cost effective drawers are perfect for wardrobes and vanities with there ultra slim and full height drawer sides. Maximize the usable space where its needed.

  • Drawer lengths from 250mm - 550mm in 50mm increments

  • Drawer Heights - 90/128/175

  • Concealed undermount full extension runner with soft close

  • Load capacity of 30kg

  • Quick assembly. 1 piece drawer side, back and front bracket

  • Colour: White

  • Adjust drilling depths and diameter easily with the included UCS

  • Inner drawers include a melamine front

  • Tested on versions 23 to 25

  • Need help installing? Limited support included with all packages

Floating Shelves
Floating Shelves
$149.00

The CV+ Floating Shelves UCS Saves You Time When Creating Doubled-UP (Sandwich) Floating Shelves.

  • Multiple Choices For Fixing

    • Timber Batten

    • Steel Rod

    • Hafele Shelf Support - 283.33.904

    • Hafele Triade (Pro) System - Standard, Maxi & Mini. Without Brackets.

    • Custom Made Bracket - Fully Adjustable Routes You Control

  • Timber Batten, Steel Rod & Custom Bracket - Set Your Own Standards On The UCS Itself . Adjust At Cabinet Level When Needed

  • Set The First / Last Distance From End Of The Shelf. Select How Many In-between. Max 6

  • This UCS Only Works With The “CV+ Floating Shelf” Cabinet Provided In The CV+ Catalogue. Make A Copy But Do Not Rename Or Delete Internal Parts To Keep Functions.

  • Need help installing? Limited support included with all packages
